Gebruikte druktank

  • Materiaal: RVS 316
  • Toestand: Gebruikte
  • Inhoud (liter): 813 L
  • Aantal stuks in stock: 1
Algemeen
Artikelnummer 03.38.AR.01
Materiaal RVS 316
Aantal 1
Inhoud (liter) 813
Type tank Druktank
Werkdruk tank (aantal Barg) 4
Proefdruk tank (aantal Barg) 6
Fixatie slede
Model van de tank Verticaal
Vorm v/d tank Cilindrish
Bodem Bolle bodem
Uitvoering tank Enkelwandig
Aantal hijsogen 4
Aantal mangaten 1
Positie van de mangat(en) Bovenaan
Afmetingen van mangaten 465
Tank met totale leegloop? Nee
Type uitlaat(en) Dupe tube 1015mm
Diameter uitlaat (mm) DN40
Vindplaats B-7711 België
Laatst gebruikt in Chemie
Voorziening reiniging tank Geen
Gewicht (kg) 387
Toestand Gebruikte
Type plaat Ja
Constructeur BSI
Bouwjaar 1991
Ontwerpcode type IC 8
Constructiedossier beschikbaar Nee
03.38.AR.01 - Gebruikte druktank
03.38.AR.01 - Gebruikte druktank
03.38.AR.01 - Gebruikte druktank
03.38.AR.01 - Gebruikte druktank
03.38.AR.01 - Gebruikte druktank
03.38.AR.01 - Gebruikte druktank
03.38.AR.01 - Gebruikte druktank
03.38.AR.01 - Gebruikte druktank
03.38.AR.01 - Gebruikte druktank
03.38.AR.01 - Gebruikte druktank
03.38.AR.01 - Gebruikte druktank
03.38.AR.01 - Gebruikte druktank
Kopkant
Uitvoering kopkant Gesloten
Detail Gesloten kopkant Bol
Afmetingen
Omtrek (mm) 3470
Cilindrische Lengte (mm) 500
Hoogte bodem (mm) 200
Totale hoogte (mm) 1500
Lengte (mm) 1150
Diameter tank (mm) 1130
Breedte (mm) 1200
Isolatie
Isolatie Nee
Opmerkingen
Omschrijving (NL) De tank is niet gekeurd • PTC: 4.300 kgs. • container n° CECU 115 239 / 4 • type IC 8 • Operating pressure 4 bar. • Test pressure 6 bar. • Bolted manhole • emptying from the top • 1 dip tube • 1 DN 40 flange • 1 DN 80 flange • 1 flange DN 25
